Object-oriented Systems Analysis and Design Using UML

This work introduces students to the overall process of systems analysis and design. It can be used as a course book for students who are first encountering systems analysis and design at any level. This second edition contains many updates, including the latest version of the UML standard, and reflects the most up to date approaches to the information systems development process. It provides a clear and comprehensive treatment of UML 1.4 in the context of the systems development life cycle, without assuming previous knowledge of analysis and design. It also discusses implementation issues in detail and gives code fragments to show possible mappings to implementation technology. Extensive use of examples and exercises from two case studies provides the reader with many opportunities to practise the application of UML.
